Name: Recycling Hazardous Waste Production Line for waste management solutions
Brand: Zhengzhou Hengyang Industrial Co., Ltd
SKU: Φούρνος
Price: 65,350.00 USD
Availability: InStock

Σπίτι > προϊόντα > EAF Dust Recycling >

Recycling Hazardous Waste Production Line for waste management solutions

Recycling Hazardous Waste Production Line

Hazardous Waste Production Line

Τόπος καταγωγής:

Κίνα

Μάρκα:

hengyang

Πιστοποίηση:

ISO9001

Αριθμό μοντέλου:

Φούρνος

Εγγραφο:

EAF Dust Recycling Rotary K...ln.pdf

Επικοινωνήστε μαζί μας

Ζητήστε μια προσφορά

Recycling Hazardous Waste Production Line for waste management solutions

Λεπτομέρειες για το προϊόν

Δυναμικό:

σύμφωνα με τα τοπικά πρότυπα των πελατών

Εγγύηση:

12 Μήνες

OEM:

αποδέχομαι

Χρώμα:

Προσαρμογή

Λειτουργία:

Παραγωγή ZinO

Όροι πληρωμής και αποστολής

Ποσότητα παραγγελίας min

Τιμή

35000-95700USD/set

Συσκευασία λεπτομέρειες

Ανακαινισμένος

Χρόνος παράδοσης

25-40 ημέρες

Όροι πληρωμής

T/T

Δυνατότητα προσφοράς

30 σετ/μήνα

ΣΧΕΤΙΚΑ ΠΡΟΪΟΝΤΑ

Acid Leaching in EAF Dust Recycling

Βρείτε την καλύτερη τιμή

Waelz Kiln Technology of EAF Dust Extracting ZinO for Industrial Recycling Solutions

Βρείτε την καλύτερη τιμή

Recycling Hazardous Waste Production Line for waste management solutions

Βρείτε την καλύτερη τιμή

Επικοινωνήστε μαζί μας

Επικοινωνήστε τώρα

Περιγραφή του προϊόντος

EAF dust is a byproduct generated during the recycling of scrap iron in electric arc furnaces (EAF). It is considered industrial waste and contains heavy metals, as well as valuable metals like zinc and iron powder.

During the EAF process, the high temperatures required to melt the feed material produce a zinc byproduct (EAF dust) that leaves the furnace along with the off-gases. The gases are filtered and the EAF dust is collected in bag houses.

The EAF dust waste steam is considered a hazardous material due to the potential for the heavy metals to leach into the ground, contaminating ground water and sewage systems.

The EAF dust generated by steel mills can be recycled in an economically viable way using the Waelz Kiln technology. The recycling process is part of the larger steel industry loop that allows the reuse of two important natural resources - zinc and iron. Recycling Hazardous Waste Production Line for waste management solutions 0

Kiln Technical Details

Specification Model (m)	The size of the kiln			Yield (t/h)	Speed (r/min)	Electrical power (kw)	Weight (t)	Remarks
Specification Model (m)	Diameter (m)	Length (m)	Gradient (%)	Yield (t/h)	Speed (r/min)	Electrical power (kw)	Weight (t)	Remarks
φ1.4×33	1.4	33	3	0.9-1.3	0.39-3.96	18.5	47.5	----
φ1.6×36	1.6	36	4	1.2-1.9	0.26-2.63	22	52	----
φ1.8×45	1.8	45	4	1.9-2.4	0.16-1.62	30	78.2	----
φ1.9×39	1.9	39	4	1.65-3	0.29-2.93	30	77.59	----
φ2.0×40	2	40	3	2.5-4	0.23-2.26	37	119.1	----
φ2.2×45	2.2	45	3.5	3.4-5.4	0.21-2.44	45	128.3	----
φ2.5×40	2.5	40	3.5	9.0-10.5	0.44-2.44	55	149.61	----
φ2.5×50	2.5	50	3	6.25-7.4	0.62-1.86	55	187.37	----
φ2.5×54	2.5	54	3.5	6.9-8.5	0.48-1.45	55	196.29	----
φ2.7×42	2.7	42	3.5	10.0-11.0	0.10-1.52	55	198.5	----
φ2.8×44	2.8	44	3.5	12.5-13.5	0.437-2.18	55	201.58	Preheater kiln
φ3.0×45	3	45	3.5	12.8-14.5	0.5-2.47	75	210.94	----
φ3.0×48	3	48	3.5	25.6-29.3	0.6-3.48	100	237
φ3.0×60	3	60	3.5	12.3-14.1	0.3-2	100	310	----
φ3.2×50	3.2	50	4	40.5-42	0.6-3	125	278
